4
Subsonics Filter Control
Variable Subsonic Filter (15Hz - 40Hz) :
The Subsonic filter will roll off all of the unwanted frequencies below 15Hz - 40Hz. This will
allow the amplifier to use that wasted power on the audible bandwidth.
5 2 Bass Boost Control
By using the bass boost function, bass notes at 42Hz are emphasized as much as 18dB.
6
Remote Control Input
Connect the Remote Control Input with the Remote Control Cable to adjust Bass-Level.
7
Low Level Filter Control
This control is used to set the desired low pass frequency (50 - 150HZ).
The filter acts to cut-off frequencies above the set-point. In general, the selected frequency
should closely match the resonant frequency of the speaker box.
8 2 Phase Shift Control
The Variable phase control allows you to adjust the relative phase relationship between
your subwoofers and/or your subwoofers & other speakers in your system. This is done by
varying the control between 0 and 1 80 degrees.
9
Bridged
12
Please see figures under BRIDGING TWO AMPLIFIERS on page #.
SUB
SONIC
15Hz 40Hz
BASS
BOOST
0 +18dB
REMOTE
LOW
PASS
50Hz 150Hz
PHASE
SHIFT
0° 180°
BRIDGED MODE
SLAVE MASTER
DATA LINK
