1. Stacker
2. Control panel
3. Carrying handle
4. Auxiliary hopper plates
5. Paper thickness adjustment strew
6. Power switch
7. Power cord
8. External Display port
9. Rear cover
10. Hopper
11. External magnifier port
12. External display
13. External magnifier
3
·Counting speed, Banknotes/min. ...................................................900/1200/1500
·Hopper capacity, Banknotes ..........................................................................500
·Stacker capacity, Banknotes .........................................................................200
·Default capacity .....................................................................................0-9999
·Range of specific counting .........................................................................1-999
·Power consumption, W .................................................................................50
·Power supply................................................... .220V/50Hz (For U.S., 110V/60Hz)
·Net weight......................................................................................5.5kg/12.1lb
·Gross weight...................................................................................6.5kg/14.3lb
·Dimensions ............ ......................................270*240*250mm,(10 3/5"*9 2/5"*9 4/5")
4
1. Main count display
Shows results and information concerning:
• Level of MG sensor sensitivity
• Level of UV sensor sensitivity
• Optical density level
• Banknote width sensitivity
2. Batch display
Depicts:
• a number of chosen banknotes in batch mode
• error messages
• changes in parameters on the main display 1
3. Digit buttons
Used for entering number values on display 2 in batch mode (counting of a specified number
of banknotes). Press any button (0-9) to enter batch mode.
20
Appearance

Specification

Control panel operation
