1.3 CONNECTING THE RMX-33I:
1.3.1 LINE SIGNALS
Connect your line sources (CD player, iPad, controller, etc.) to the corresponding iPad/CD channel inputs for channels 1 – 3 -25-.
1.3.2 PHONO SIGNALS
Connect your phono sources to the corresponding phono channel inputs of channels 1 and 2 -25-.
Connect your grounding cable of your turntables to the GND grounding screws -26-.
1.3.3 MICROPHONE SIGNAL
Connect your microphone to the input for DJ Mic -22-.
1.3.4 HEADPHONES
Connect your headphones to one of the headphones inputs -21-.
1.3.5 FADER-START
Connect the fader-start cables of your CD player to the Fader-Start Connection -27-.
1.3.6 MASTER OUTPUT
Connect your sound system to Master Out -33- (RCA) or Master Out Balanced (XLR) -34-.
1.3.7 MONITOR OUTPUT
Connect your monitoring system to Booth Out -31-.
1.3.8 POWER SUPPLY
Connect the power cable to the Power Connection -24-.
Connect the power cable to your power outlet.
1.3.9 IPAD SPLIT CONNECTION
It is possible to connect your iPad or Android tablet for audio transmission via a 3.5 mm jack connection. To do so, connect the included iPad Split
Cable by connecting the black plug side to your tablet or smartphone and connect the red/white plug side to the iPad Split Connection -28-. (White
= iPad(l) / Red = iPad(r))
Notes:
- The iPad(l) and iPad(r) connections are doubled mono inputs; the left and right signal are doubled and put out in stereo.
- This is convenient when using a DJ app such as DJAY by Algoriddim and activating the CUE SPLIT mode; in this mode the stereo output of
your tablet will be splitted for master signal & monitoring signal.
- This way you can monitor a signal with your mixer and tablet and the second signal can be used as master output, while deck A & B can be
mixed comfortably via channel 1 & 2; to do so put the input select switch to iPAD (L) and iPAD 8R) respectively.
- If you put the input select switch on the mic/aux channel to iPAD (S), the normal tablet signal will be put out in stereo
2. OPERATION
2.1 POWER UP
After all connections have been carried out, you can turn on the device via the ON/OFF Switch -34-.
2.2 SIGNAL INPUT SELECT
Via the Signal Input Select Switch -1- you can select between iPad(l)/(r), CD and phono sources. Please observe the captions of the single signal
input switches.
Via the Signal Input Select Switch -1.1- you can select between microphone, AUX and iPad as source for the Mic/AUX/iPAD(s) channel.
2.3 GAIN
Via the Gain Dials -2- you can adjust the input volume for channels 1 - 3. Make sure that peak signals remain within the yellow range of the LED
indicator -4-.
Use the Mic/Aux Level Dial -13- to adjust the volume of the MIC/AUX/iPAD(s) channel. Make sure that the Peak LED -14- is only illuminated during
peak highs.
2.4 EQUALIZER
With the 3-Band Equalizers -3- you can adjust low, mid and high frequencies for channels 1 - 3.
Via the 2-Band Equalizer -19- you can adjust low and high frequencies for the MIC/AUX/iPAD(s) channel.
2.5 LINEFADER
The Linefaders -7- are used to adjust the output volume for channels 1 - 3.
The Linefader's curve can be adjusted with the help of the Linefader Curve Dial -10-.
In the 12 o'clock position the curve is linear.
By turning clockwise, the CUT limit will be moved to the upper fader pass.
By turning counter-clockwise, the CUT limit will be moved to the lower fader pass.
2.6 CROSSFADER
With the Crossfader -9- it is possible to switch between the left and right crossfader channel. The crossfader's curve can be adjusted via the Cross-
fader Curve Dial -11-. By turning counter-clockwise, the crossfader becomes "sharp", namely good for scratching and cutting.
By turning clockwise, the crossfader becomes "smooth", namely good for long mixes.
You can use the Crossfader Assign Switch -8- to assign the crossfader sides A&B to channels 1 and 2.
You also have the possibility to exchange the crossfader with a Reloop RMX Innofader by Audio Innovate. This extremely high-quality crossfader
is optimized for scratching and guarantees ideal performance and longevity.
Further information can be found under www.reloop.com.
2.7 FADER-START / CROSSFADER-START
If you have connected appropriate CD players to the RMX-33i (as described under Connections, item 1.6), you can trigger these via the Crossfader
-9- or Linefader -7-, respectively.
To do so, activate the Fader-Start Switch -29- or the Crossfader-Start Switch -30-, respectively.
CROSSFADER-START:
If you move the crossfader all the way to the left, the CD player connected to Fader- Start Port "A" will switch to playback mode and the CD player
connected to Fader-Start Port "B" will return to the last saved cue point and switch to pause mode.
If you move the crossfader all the way to the right, the CD player connected to Fader-Start Port "B" will switch to playback mode and CD player
connected to Fader-Start Port "A" will return to the last saved cue point and switch to pause mode.
