Component Placement; Component Positions Component Positions; List Of Components - Nibe F1330 Montage- Und Bedienungsanleitung

121
129
130
133
121 Connection to the distribution system
122 Connection from the distribution system
123 Connection to the collector
124 Connection from the collector
5 Heat transfer fluid from HP
4 Heat transfer fluid to HP
71 Heat medium to HP
70&72 Heat medium from HP
129 Shuttle valve, active cooling
130 Shuttle valve, active cooling
131 Shuttle valve, passive cooling
132 Shuttle valve, passive cooling
133 Terminal blocks, supply and signal
134 Cable inlet, supply and signal

Component placement

122
132
131

List of components

134 5
HPAC 42 HPAC 42
121
122
123 124
71 70 72
4
19 19
