Option2 ： Ceiling Mounting
■
Follow the steps below to install the EAP with the provided accessories:
Washers
(Qty.3)
1
Remove the ceiling tile.
2
Place the mounting bracket in the center
of the ceiling tile. Mark the three positions
of the screw holes and a 10mm hole for
the Ethernet cable to feed through. Drill
three 4mm holes and a 10mm hole for the
Ethernet cable.
3
Secure the mounting bracket to the ceiling
tile using three M3x30 pan-head screws,
washers and wing nuts.
M3×30 Pan-head Screws
(Qty.3)
English
Wing Nuts
(Qty.3)
Hole for Ethernet cable
X3
