Technical Features - Trevi Rda 70 Br Gebrauchshinweise

WIRELESS FUNCTION
1. Set the function switch (4) to the MUSIC position without USB memory and
MicroSD card inserted, the Wireless function will be activated;
2. Follow the instructions of your device to search for the device;
3. Search for the device named "RDA 70 BR", pair and enter PIN "0000" if required;
4. Once paired, the device will emit a confirmation message.
5. Start playing the music track from your device to begin listening; press NEXT
(11) or PREV (9) buttons to select next/previous track;
6. Press the PLAY/PAUSE(10) button to pause track playback, press it again to
resume playback.

TECHNICAL FEATURES

Power supply: .................................................3.7V
Reception range: ...........................................FM 87.5 - 108.0 MHz
Wireless transmission power: ...................2.5mW
Wireless transmission frequency: .............2.4GHz
Dimensions: ................................................. 185 x 165 x 77 mm
Weight:
INFORMATION ON THE REMOVAL AND DISPOSAL OF
BATTERIES
Attention: the removal and disposal operation is reserved exclusively for
specialized technical personnel!
1. Open the battery compartment on the back of the device.
2. Locate the battery and replace it with one of equal capacity and specifications;
3. Close the battery compartment.
Whatever the type of exhausted battery, it must not be thrown into household
waste, fire or water. Each type of spent battery must be recycled or disposed of at
the appropriate dedicated collection centers.
10
................................................. AM 522 - 1620 KHz
................................................. SW
................................................. 600 gr.
1200mAh lithium battery
rechargeable via:
USB type-C 5V
5.6 - 22 MHz
1A socket
