4.1 ASSEMBLING THE
COMPONENTS
4.1.a - Mounting the brush (Fig. 6)
- Lift the machine on vertically as shown in
the figure.
- Insert the brush (9) by inserting it in the
axle (24), then turn it until it is secured in
the holder (25) and a "click" is heard.
- Reposition the machine on the ground.
WARNING:
Use only brushes provided by the manu-
facturer according to the model of the ma-
chine.
Using other types of brushes may com-
promise the safety of the machine.
4.1.b - Positioning of the handle (Fig.
7)
- Unlock the handle (1) pulling the lever (3)
and lift it placing it in the desired position.
4.1.c - Battery mounting for the batte-
ry version only (Fig. 8a)
- Insert the battery (6) in the socket (26)
completely and then turn it towards the
machine until a click is heard.
4.1.d - Charger mounting for the elec-
tric version only (Fig. 8)
- Check if the power supply cable (23) is
correctly inserted in the charger (22).
- Insert the charger (22) in the socket (26)
completely and then turn it towards the
machine until a click is heard.
WARNING:
- Make sure that the mains system is
equipped with an RCD (circuit breaker).
- Unwind the electric power cable com-
pletely before connecting it to the
mains socket.
- Use an electrical extension lead only
if in perfect condition; ensure that the
power rating.
- Never let the power cable run over
sharp edges and do not tread on it.
- The socket must be easily accessible.
5.1 CHARGING THE
BATTERY (Fig. 9)
(IF EQUIPPED)
