Room preparation guidelines

Distances
Figures 1, 2, and 3 illustrate the microphone placement guidelines.
To meet these guidelines, use one of the Cisco Ceiling Microphone
Pro mounting kits as instructed in this guide.
Fig. 1: Optimal range max
D15536.02 | © 2024 Cisco Systems, Inc. All rights reserved.
R
R 3.5 m/
R
12 ft
3 - 5 m/
10 - 16 ft
Fig. 3: Distance between microphones
2 - 3.5 m/
7 - 12 ft
Fig. 2: Distance to floor
