Dimensions And Features - Cisco Ceiling Microphone Pro Installationshandbuch

260 mm (10.3 in)
260 mm (10.3 in)

Dimensions and features

48 mm
(2 in)
420 mm/16.5 in
260 mm/10.2 in
Microphone status LED
Green: in call, ON
Red: in call, MUTE
White: configuration mode
D15536.02 | © 2024 Cisco Systems, Inc. All rights reserved.
48 mm
260 mm (10.3 in)
(2 in)
24 mm 24 mm
24 mm
(1 in) (1 in)
(1 in)
48 mm/1.9 in
Connector panel
1. Ethernet (PoE)
2. Maintenance
3. Factory reset
4. Power indicator
VESA
100 x 100 mm
1 2 3 4
24 mm
(1 in)
3
