FOR A COMPLETEDESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE
REFER
GENERAL
Solid
Type :
channel
Stereo
FM STEREO/SDK
RG-6000G/RG-9000:
Power source: 12V (for negative earthing car only)
Output impedance:
4 ohms/channel
Semiconductors:
RG-6000H:
RG-6000G:
RG-9000:
Output power:
8W + 8W (maximum
5W + 5W (at 10% distortion)
SIN:
54dB
Dimensions:
160(W) x 120(D) x 44(H) mm
Weight:
1.2 Kg
PARTS
Power ON-OF F(Volume/BaIance
Tone Control Selector Button
2.
3. FM-MONO Selector Button
FM Band Selector Button
4.
5. MW Band Selector Button
LW Band Selector Button
6.
7. Tuning Control Knob
8.
CassetteEjection/ Fast-forward Winding Button
9. Cassette Compartment
10. SDK Indicator (RG-6000H only)
11. FM Stereo Indicator
12. Earth Terminal
13. Antenna (Aerial) Socket
14.
Speaker Terminal
15. DC Input Terminal
Figure 2-3
TO THE OPERATION MAUNAL.
SPECIFICATIONS
State In-dash Type 4-Track
Full Auto Stop Cassette Car
Player with built-in LW/MW/FM/
3 band Radio.
without SDK
13-transistor (I-FET)
16 diode (2-LED) and
7-1C (integrated circuit)
8-transistor (I-FET)
8 diode (I-LED) and
5-IC (integrated circuit)
power)
LAYOUT
control
Knob
+0
164
mm
—0.5
I Turn
DIAL CORD STRINGING
TAPE PLAYER
2-
Playback system:
Using tape:
Tape speed:
Wow and flutter:
Frequency response:
Fast forward time:
Motor:
RADIO SECTION
Frequency range:
Sensitivity:
Specificationsaresubject to changewithout prior notice.
2
8
Figure 2-1
12
13
5.5Turn
Figure 2-2
-2-
SECTION
4-track, 2-channel Stereo
Philips standard compact cassettetape
4.75 cm/sec.
0.35% (DIN 45 511)
10kHz/—6dB
120 seconds (@ C-60 cassettetape)
D.C. motor with mechanical governor
LW 150 285kHz
MW 520 — 1,620kHz
FM 87.6 — 108MHz
LW/MW 452kHz
FM 10.7MHz
LW 400uV/20dB
MW 40gV/20dB
FM 2.5gv
3
4 S 6
9
10
FRONT PARTS LAYOUT (RG-6000H)
REAR PARTS LAYOUT
7
11
14
15
(RG-6000H)
