the upper guard (2).
6. Pay attention to reposition all pieces following the
dismounting procedures in reverse order.
7. Tighten the hexagonal bolt (19) securely, but do not
over-tighten.
8. Be sure the spindle lock (5) is released so the
cutting wheel (4) turns freely.
9. Pull down the side guard (3) and lower the handle
(1) to make sure that the side guard (3) moves properly.
10. After the cutting wheel (4) is installed, switch on the
machine and let the cutting wheel (4) turn for a minute
to check if it turns without fluttering.
Replacing carbon brushes [F9]
The carbon brushes need to be regularly checked.
When carbon brushes become worn near the 'wear
limit' (minimum permissible length 5-6 mm), they must
be replaced. Both carbon brushes should be replaced
at the same time. Use only identical carbon brushes.
1. Remove the carbon brush holder cap (10) using a
screwdriver.
2. Take out the worn carbon brushes, insert the new
ones and secure the carbon brush holder cap (10).
3. Let the tool run idle for 10 minutes with the new
carbon brushes.

ENVIRONMENTAL PROTECTION

Recycle raw materials instead of
disposing as waste.
Tool, accessories and packaging should be sorted for
environment-friendly recycling.
The plastic components are labeled for categorized
recycling. These instructions are printed on recycled
paper manufactured without chlorine.
ATTENTION! DO NOT ATTEMPT TO REPAIR THE PRODUCT BY YOURSELF AND DO NOT
TAMPER WITH IT! Any operation of repairing or extraordinary maintenance must be carried
out only by a qualified and authorized IVT Service Center. Do not try to modify any internal
part of the product! THIS WILL COMPLETELY VOID THE WARRANTY AND IT COULD CAUSE
SERIOUS INJURY AND DAMAGE.
