Instruction manual
Switching off
To stop the tool, release the on/off switch (7) and the
lock-off button (6).
EN
OPERATING INSTRUCTIONS
Making a cut
1. Clamp the workpiece securely in the vise.
2. Switch on the machine and wait for the motor to
reach its top speed.
3. Push down the cutting head by the handle (1)
until the cutting wheel (4) makes slight contact with the
workpiece.
4. Move the cutting wheel (4) smoothly through the
material you want to cut.
5. Press down the handle (1) firmly and evenly during
the cutting operation.
CAUTION! Do not apply excessive
pressure on the handle (1) when
cutting. Too much pressure may result
in overload of the motor, decreased
cutting efficiency and damage to the
cutting wheel (4). Too little pressure
on the handle (1) may result in more
sparks and premature cutting wheel
(4) wear.
CAUTION! If the cutting wheel (4)
stops during operation, makes an odd
noise or begins to vibrate, switch off
the tool immediately. Then check the
condition of the tool and cutting wheel
(4).
6. (Full cut) When the cut is completed, switch off the
tool and wait until the cutting wheel (4) has come to a
complete stop before returning the handle (1) to the fully
elevated position. (Partial cut) When cutting only part
of the way into a workpiece, raise the handle (1) while
the cutting wheel (4) is rotating because switching off
during the cut may cause damage to the edge of the
cutting wheel (4).
CAUTION! The cutting wheel
continues to rotate after the machine
is switched off. Never remove or
install a workpiece material while the
cutting wheel (4) is rotating, to avoid
serious personal injury.
WARNING! Do not touch the cutting
wheel (4), workpiece or cutting chips
immediately after operation; they may
be extremely hot and could burn your
skin.

MAINTENANCE AND STORAGE

Before any work on the device itself,
pull the mains plug.
∙ Always keep the tool and the ventilation slots (if
present) cleaned. Regular cleaning and maintenance of
the appliance will ensure efficiency and prolong the life
of your tool.
∙ If the tool should fail despite the rigorous
manufacturing and testing procedures, the repair should
be carried out by an authorized IVT customer service.
∙ Keep all nuts, bolts, and screws tight, to be sure the
tool is in safe working condition.
∙ Replace worn or damaged parts for safety.
∙ Use only original spare parts. Parts not produced
by manufacturer may cause poor fit and possible injury.
∙ Store the tool in a dry room out of reach of kids and
away from any flammable material.
∙ Never wet the device or spray water on it!
∙ Remove dust and dirt regularly from the machine.
∙ Never use caustic agents to clean plastic parts.
∙ Keep all ventilation slots free and clean, blow out
motor regularly with compressed air.
Installing/removing the cutting wheel (4)
WARNING!
assembling the cutting wheel (4) make
sure that the machine is switched off
and the power plug is disconnected.
1. Lift up the side guard (3).
2. Press the spindle lock (5) behind the upper guard
(2) and loosen the hexagonal bolt (19). [F7]
3. Removing the hexagonal bolt (19) enables to
(4)
remove also flange washer (20), outer flange (21),
cutting wheel (4), spacer (22) and inner flange (8), in
order. [F8]
4. Wipe spindle, inner flange (8) and outer flange (21)
clean from any debris.
5. Install a new suitable cutting wheel (4). Make sure
that the direction of the arrow on the surface of the
cutting wheel (4) matches the direction of the arrow on
14
When replacing or
