Sun Microsystems SPARCstorage Benutzerhandbuch Seite 19

1
6
3
2
Narrow Host
Bus Adapter Host Bus Adapter
with N and W
N
Wide Host
Host Bus Adapter
Bus Adapter
with all W
W
Wide Host Bus
Adapter with
Host Bus Adapter
both N and W
W
N = 50-pin narrow SCSI II bus connection
W = 68-pin wide SCSI III bus connection
Figure A-2
Service Labels
Customer Replaceable Parts
1* Enclosure, complete
2* Drive
Service Technician Parts
5
3 LED cable
4 Drive Board
4
5 Power Supply
6 Fan
*50-68-pin, 0.8 meter
*50-68-pin, 2.0 meter
*68-68-pin, 0.8 meter
*68-68-pin, 2.0 meter
CABLING
Other
UniPack
N N
W
50-50
50-68
Other
UniPack
W W W
68-68
68-68
UniPack
UniPack
W W W
68-68 68-68
T = Terminator
A = Auto-terminated
Service Label for Hard Disk Enclosures
PARTS
595-3709-xx
See old drive
530-2183-xx
501-2790-xx
300-1282-xx
370-1986-xx
SCSI Cables
530-2115-xx
530-2228-xx
530-1884-xx
530-1885-xx
UniPack
W W A
68-68
UniPack
W W
A
68-68
Other
W N T
68-50
802-3231-10
Rev A of August 1995
A
9
