Sun Microsystems SPARCstorage Benutzerhandbuch Seite 18

A
9
2
8
1
8
7
3
4
Narrow Host
Bus Adapter Host Bus Adapter
with N and W
N
50-50
Wide Host
Host Bus Adapter
Bus Adapter
with all W
W
68-68
Wide Host Bus
Adapter with
Host Bus Adapter
both N and W
W
68-68
N = 50-pin narrow SCSI II bus connection
W = 68-pin wide SCSI III bus connection
Figure A-1 Service Label for Tape and Compact Disc Enclosures
SPARCstorage UniPack User's Guide—August 1996
PARTS
Customer Replaceable Parts
1* Enclosure, complete
2* Drive
9* Foam Air Dam
Service Technician Parts
3 DC Power Cable
4 SCSI Target ID Cable, Narrow 530-2181-xx
SCSI Target ID Cable, Wide
6
5 LED Cable
6 Board/Ribbon Cable, 50-pin
5 Board/Ribbon Cable, 68-pin
7 Power Supply
8 Fan
SCSI Cables
*50-68-pin, 1.2 meter
*50-68-pin, 2.0 meter
*68-68-pin, 0.8 meter
*68-68-pin, 2.0 meter
CABLING
Other
UniPack
N N
W
50-68
Other
UniPack
W W W
68-68
UniPack
UniPack
W W W
68-68
T = Terminator
A = Auto-terminated
595-3711-xx
See old drive
330-2129-xx
530-2179-xx
530-2354-xx
530-2183-xx
501-2791-xx
501-3108-xx
300-1282-xx
370-1986-xx
530-2115-xx
530-2228-xx
530-1884-xx
530-1885-xx
UniPack
W W A
68-68
UniPack
W W
A
68-68
Other
W N T
68-50
802-3530-11
Rev A of September 1996
