Attaching Front Plate to Screen Using VESA 200 x 100 mm Mounting Pattern
• If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly
secured, damage may occur to screen or product may fail.
Attach adapter plates (J) to tilt plate of arm
4
assembly (A) using four M5 x 6 mm screws (K) and
four #10 flat washers (L).
J
TILT PLATE
L
Insert one M4 screw (F or G) through bottom hole of
6
adapter plate (J) as shown in figure 6.1.
A
K
J
F or G
WARNING
Insert two M4 x 12 mm screws (F) into top two holes
5
of screen, leaving approximately 1/4" (6.3 mm) of
exposed thread. Hook screws onto slots of adapter
plates (J) as shown in figure 5.1
NOTE: If hole pattern is in a pocket, insert two
M4 x 20 mm screws (G) with two retaining spacers (H)
into top two holes of screen.
Screen may appear
slightly different than
illustrated
fig. 6.1
7 of 18
*For screens with
a hole pattern in a
pocket, spacers (H)
F
go between adapter
plate and screen.
ISSUED: 02-05-09 SHEET #: 202-9338-1
H
fig. 5.1
