ROHO DRY FLOATATION Handbuch Seite 8

PRODUCT SPECIFICATIONS, Continued
Standard Overlay Section
Standard Overlay System
(4 Sections)
Bariatric Overlay System
(8 Sections)
Bariatric Overlay System
(12 Sections)
Standard SOFFLEX 2 Section
Standard SOFFLEX 2 System
(3 Sections)
PRODIGY Section
PRODIGY System
(3 Sections)
NOTE: All measurements are approximate.
ADJUSTMENT INSTRUCTIONS FOR:
• Standard Overlay
• Bariatric Overlay
1: For mattress overlays: Remove all bed
linens except the support mattress pad or
sheet from existing bed mattress. Place the
mattress overlay sections cell side up, on
top of the bed mattress. Align the mattress
overlay sections and snap together.
For the O.R. Pad: Place the section or system
on the operating table, cells facing up.
Width x Length x
Height (in.)
33.75 x 19.25 x 3.25
33.75 x 75 x 3.25
39.5 x 75 x 3.25
41.5 x 75 x 3.25
54.5 x 75 x 3.25
60 x 75 x 3.25
48.5 x 75 x 3.25
36 x 27.5 x 3.5
36 x 81.75 x 3.5
36 x 27.5 x 3.5
36 x 81.75 x 3.5
• SOFFLEX 2
• PRODIGY
2: Turn the valve counter-clockwise to open.
NOTE: If there is more than one valve per
section, only open one.
NOTE: SOFFLEX 2 and PRODIGY, valves are
located on the bottom surface.
8
Width x Length x
Height (cm)
86 x 49 x 8.5
86 x 190.5 x 8.5
100.5 x 190.5 x 8.5
105.5 x 190.5 x 8.5
138.5 x 190.5 x 8.5
152.5 x 190.5 x 8.5
123 x 190.5 x 8.5
91.5 x 70 x 9
91.5 x 207.5 x 9
91.5 x 70 x 9
91.5 x 207.5 x 9
• O.R. Pad
Weight Weight
(lb.) (kg)
8.0 3.6
32.0 14.4
36.5 16.5
38.5 17.4
47.5 21.5
50.5 22.9
45.0 20.4
2.25 1.0
6.5 2.9
3.25 1.4
9.6 4.3
