ProControl Charging / Battery
Maintenance and Replacement
Your ProControl™ transmitter uses a rechargeable
battery pack. While the transmitter is off and connected to
the charger, the charge status will be periodically
displayed as either "Charging" or "Charged". While the
transmitter is on and connected to the charger, the charge
status will not change, only regular information will be
displayed.
NOTE: The ProControl™ wireless transmitter uses a
Lithium-Polymer rechargeable battery. It is recom-
mended that the transmitter
over-night or under circumstances where the vehicle cab
temperature will fall to 0°C (32°F) or below. Tempera-
tures below this point will inhibit the battery from charg-
ing. Should this occur, allow the transmitter to warm
before charging.
To preserve the life of the battery, it MUST be charged at
least once every 8 months that the transmitter is not in
use. Failure to do so will cause the battery to no longer
take a charge. A new battery will need to be purchased.
Although the ProControl™ battery is rechargeable it will
require replacement after a finite number of charge
cycles. To access the battery pack remove 2 screws
securing battery cover. (See Figure 1-10). Remove
battery cover to expose battery pack.
BATTERY
COVER
Figure 1-10
Once battery pack is exposed, move to one side to
expose the 4 pin connector that connects the battery
wires to the circuit board. (See Figure 1-11). Unplug
connector and discard old battery. For installation, follow
steps in reverse.
BATTERY
CONNECTOR
Figure 1-11
not
be stored in the vehicle
SERIAL
TAG
COVER
SCREWS
TM
ProControl Transmitter
Mounting Instructions
Your ProControl™ transmitter is equipped with a Dash
Mount Clip for mounting purposes.
Fasten the mounting clip in the desired location using the
2 screw holes. (See Figure 1-12).
NOTE: Be certain control mounting does not obstruct
items that are critical to safely operating your vehicle.
DASH MOUNT CLIP
Figure 1-12
Secure the ProControl™ transmitter by sliding downward
into the dash mounting clip. (See Figure 1-13).
TM
ProControl
DASH
MOUNT
CLIP
Figure 1-13
MOUNTING SCREW
LOCATIONS
SLIDE
TRANSMITTER
INTO CLIP
