Manual for: SUMMIT EasyFloat UV 40W / 80W / 130W
EN

3. Installation

Before installing the system check the delivery for completeness and signs for damage. Contact the supplier immediately if
the product is incomplete or damaged. Check the glass carefully for any signs of damage.
The delivery of a UV system includes:
• Float cushion and enclosure;
• Control panel with 9 metre cable
• Stainless steel fixture with lamp and quartz glass
• Instruction manual;
When everything is complete installation can begin. When handling the EasyFloat UV system always make sure that the
power cable is disconnected. Make sure that the tank or reservoir is properly earthed to prevent an stray voltage in case
of an short circuit.
Stap 1
Insert the UV lamp + stainless steel fixture
through the floating cushion and inside the
frame. Make sure that the bottom of the quartz
glass goes inside the holder of the frame.
Stap 2
When this is completed connect the lamp cable
on the floating cushion using the strain relief.
Ensure a tolerance of 10 cm to remove any
stress on the cable.
