EURORACK GO BRACKET
The Go Bracket is designed to join two Behringer Eurorack Go cases together to form a single, four row
560 hp case.
In the package you get two brackets, one for the left and one for the right, twelve screws, and two stick-on
rubber pads for the feet.
It is recommended that installation takes place while the cases are unpopulated.
Please note that the screws which are removed also hold the rack rails in place, so care should be taken while
removing and replacing them. If the rails move then they should be carefully re-aligned with the relevant screw
hole during installation.
Installation
1. Peel the backing off the rubber pads, and carefully attach them to the feet of the brackets.
2. Note that they use a strong adhesive, so may not be easily removed.
3. Place the two Go cases on their ends, on a flat level surface. For illustrative purposes the right hand bracket
is being fitted here.
4. Remove the three identified screws from each case, taking care not to dislodge the rack rails.
Bottom case left Bottom case right
Top case left
5. Identify the correct bracket for the side in question.
6. Using the screws supplied with the bracket carefully attach the bracket to the cases. Tighten them up once
all screws and holes are aligned.
Right hand bracket fitted
7. Carefully turn the cases over.
8. Repeat steps 4 – 6 on the other side of the case.
Your double Go case is now ready for use.
Quick Start Guide
Top case right
