CONNECTION DIAGRAM

1. Disconnect the general power supply before starting work
2. Connect the wires according to the following diagrams
3. Insert the module in the box or in the chosen place
4. Connect the general power supply and follow the association instructions with the App.
With mounting clip
COMPATIBILITY WITH VOICE ASSISTANTS
Compatible with Amazon Alexa and Google Home.
The devices can be automatically found by modern voice control systems.
Download the "Amazon Alexa" or "Google Home" App to connect devices.
Selecting a device in the "
control systems.
Connection diagram
Reset key
Without mounting clip
" menu of the Hom-io App provides a guide for connecting to voice
