1. General Data and Description
These motors are designed for the automation of roller shutter systems (roller shutters). They
comprise the induction condenser motor with thermal protection, brake, gear box, electromechanical
limit switches and a control unit with an inbuilt radio receiver. Installed in octagonal shaft.

2. Technical Characteristics

These technical characteristics are applied to the ambient temperature of 20°С (±5°С)
and supply voltage of 230V/50Hz.
Table 1 – Technical characteristics for motors of AM0/R, AM0/RD, AM1/R series
Models
Torque,
N·m
AM0/06-28R 6
AM0/10-17R 10
AM0/10-17RD 10
AM1/10-15R 10
AM1/20-15R 20
AM1/30-15R 30
AM1/40-15R 40
AM1/50-12R 50
*When using a commercially special additional kit of adapter and ring
Table 2 – General technical characteristics for motors of AM0/R, AM0/RD, AM1/R series
Supply voltage, V
Power frequency, Hz
Max. continuous operating time, min
Operating mode
Thermal protection, °С
Operating frequency of radio control, MHz
Radiocode
Max. number of recordable remote controls, pcs.
Protection rating
Protection class
Power cable length, m
Quantity of wires in cable
Wire section of cable, mm
Operating temperature range, °С

3. Mounting and connection

Recommended order for mounting the electric motor (see also the illustrated instructions part)
Only a professional electrician may install, connect and commission your electric motor. The
electrician must be fully aware of all specific features of your local electric network.
Please, keep this Operation Manual throughout the entire life of the product.
The instructions provided in this Operation Manual should be qualified as basic sample guidance
since mounting spots and your installation kit may vary. The installer is fully responsible for finding
the most appropriate mounting solution.
OPERATION MANUAL
Tubular Electric Motors of
AM0/R, AM1/R Series
Shaft Max. number
rotational of shaft
speed, rpm rotations
28
36
17
17 17
15
15
15 22
15
12
Parameter
2
Parameters
Size used Power
octagonal consumption,
shaft W
40 121
112
145
60
191
70*
198
205
2
Weight, Width, Length,
kg mm
1.54 40
1.54 40
1.41 40
2.21 71.5
2.38 71.5
2.67 71.5
2.85 71.5
2.93 71.5
.
Value
230 (±10%)
50
4
S2
140
433.92
Dynamic
20
IP44
I
2
3
0.75
-20 ... +50
mm
564
564
483
590
590
620
620
620
