QuickStart | inSert/replace ribbon
Place the LabelMax VS1 on a flat, secure surface and open the case. Turn it on using the blue main
The WLAN connection between VS1 and the laptop is established automatically within a minute.
Note: A WLAN connection will be established with the printer name and the last digits of the LabelMax serial num-
Insert/replace ribbon
2
Insert the right side of the ribbon
first. Then place the left side into
the hole on the ribbon take-up hub
(green).
Pull the transparent part of the
ribbon through the printhead and
attach it to the take-up roller using
a piece of tape.
QUICKSTART GUIDE
Hello, here I am!
Your new colleague for labels, signs, and tags in mobile use!
I'm very easygoing, so let's get started:
Ready to print
I'm already equipped with a ribbon and a foil cassette!
Power on

Get started

Then start the SignMax software on the laptop.
Now you can design and print your sign exactly as you want!
ber, e.g., LabelMaxVS1-12345.
The password for the WLAN connection is: labelmax.
1
1.
Press the printhead release button
to open the printhead mechanism.
4.
Turn the take-up plate until the
plastic leader is firmly wound and
the black section of the ribbon rests
against the printhead.
1
switch.
2
2. 2.
5.
2 1
Insert the right side of the ribbon
supply spindle, marked "R", into
the ribbon supply hub (1). Then
insert the left side into the hole on
the left ribbon supply hub, marked
"green" (2).
Close the printhead mechanism
with both hands. Make sure the
latches engage correctly.
DE
3.
6.
7
