CEA SIXTY Bedienungsanleitung Seite 189

DC IN
+
-
RD BK
red black
(NOT INCLUDED)
HOME AUTOMATION
SYSTEMS
CLAMP
1 2
OUT INPUT
L+ L-
IN COM
OR OR BK
orange orange black
BK BK
black black
V+ V- N
GN
RD BK BU
YE
red black green- blue
yellow
3 4
GN
green
N L
GN
BU BN
YE
green- blue brown
yellow
L
BN
brown
Electrical cables and clamps are not included
Nominal cross-sectional area
1 1,5 mm²
÷
OUT
V+ V-
L+ L-
OR OR
RD BK
red black orange orange
BK BK
black black
Rated Cable for fixed
current
(A)
≤3
>3 and ≤6
>6 and ≤10
>10 and ≤16
>16 and ≤25
>25 and ≤32
>32 and ≤50
>50 and ≤63
INPUT
IN COM
BK GN
black green
wiring
(mm²)
1 2,5
÷
1 2,5
÷
1 2,5
÷
1,5 4
÷
2,5 6
÷
4 10
÷
6 16
÷
10 25
÷
189
