STEERING YOUR MODEL

CAUTION
To avoid loss of control: ALWAYS move the controls S-L-O-W-L-Y!
(1)
GB // 16
(2)
Forward
You can make the model move forwards or backwards by
operating the left control lever.
left
You can make the model steer to the left or right by opera-
ting the right control lever.
(3)
(2)
(1) The support legs can be operated via the remote control
by pressing the "Support legs" button.
(2) The "Couple/uncouple truck" function can be operated
by pressing the relevant button on the remote control.
Coupling indicator (3) must always be fully open or closed!!
By pressing the "Ramp" button, this function can be ope-
rated using the remote control.
Backward
right
(1)
Ramp raise and lower
