teaching-in has been successful (how long it will
flash for depends on how much configuration
work has been competed).
• If no teach-in is carried out, teach-in mode will
be exited automatically after 20 seconds. If other
devices are also in teach-in mode, they will be
taught-in.
Note: If the wireless motion detector has
already been taught-in to a central control unit
and is thus blocked for direct teach-in, it can
still be put into teach-in mode as described
above. However, direct teach-in is not possible.

8.1.2 Teaching-in taking a brightness threshold

into account (approx. 10 Lux)
• Remove the device from the wall mount (F) and
open the battery compartment (E).
• Press the teach-in button (D) on the HomeMatic
wireless infrared motion detector for approx. 4
seconds until the device LED starts to flash red.
• Press and release the teach-in button (D) on the
motion detector. The device LED flashes orange.
The teach-in procedure can now be cancelled by
pressing the teach-in button (D) briefly; this will
cause the device LED to light up red.
