Function and device overview

3 Function and device overview
The Homematic IP Motion Detector with Brightness Sen-
sor is designed especially for indoor application. The de-
vice detects movements as well as light intensity with an
integrated brightness sensor.
This high performance motion detector can be used for
security applications, for example. In connection with
other Homematic IP devices an alarm can be triggered if
motions are detected.
Thanks to the detection distance of up to 12 meters and
a detection angle of 105 ° (approx.) as well as different
mounting possibilities the detection range can be opti-
mised to the particular surroundings. You can mount the
motion detector anywhere on a wall, in a corner or place
it in the supplied stand.
Brief changes in the level of brightness are filtered out.
Thus, unintended response of the motion detector can
be avoided. The brightness level for triggering and the
level of sensitivity can be flexibly adjusted.
Thanks to the integrated tamper contact you are imme-
diately informed via the app about unauthorised removal
or manipulation of the motion detector.
30
Device overview (see figure 1):
(A) PIR sensor
(B) System button and device LED
(C)
Battery compartment
Accessory components (see figure 2):
(D) Stand and battery compartment cover
(E)
Wall mounting bracket and battery compartment
cover
4

General system information

This device is part of the Homematic IP smart home
system and works with the HmIP radio protocol. All
Homematic IP devices can be configured comfortably
and individually with a smartphone via the Homematic
IP app. The available functions provided by the Home-
matic IP system in combination with other components
are described in the Homematic IP User Guide. All cur-
rent technical documents and updates are provided at
www.eQ-3.de.
