RODEC
2)
Frayed cords and broken adapters may cause fire or shock hazard. Do not damage the power
cord or adapter. When removing the power adapter from wall outlet, be sure to unplug by
holding the adapter and not by pulling the cord.
3)
Operate the set only from mains power source which is indicated on the rating label of the
adapter.
4)
Do not use chemical products to clean the set.
INSTALLATION
1)
The set can be used in every position.
2)
Don not place the set into direct sunlight, or in a warm moist or dusty place.
3)
To avoid disturbances, do not place the set nearby disturbing apparatuses.
FRONTPANEL
1)
Power "ON" indicator
This indicator lights up when the power is on.
2)
Signal indicators
These indicators light up when the input signal does not exceed the adjusted maximum level.
3)
MAX indicators
These LED's light up when the input level is higher than the adjusted maximum level, the
Audio level controller is active.
CONNECTIONS AND CONTROL
A)
Inputs
The output signal of the mixing table (pre-amplifier) is connected to these connectors.
B)
Outputs
The ouput signal of these connectors is connected to the input of the power-amplifier.
C)
Multi connector
The orange multi connector exist of two parts. On the left side a 3-pole connector to connect
the optional remote control. On this connector a wire is mounted between the pins 1 and 2,
these may only be removed when you connect a remote control.
On the right side the 5-pole connector to connect the power supply.
D)
MAX input level controls
With these potentiometers the nominal input level will be adjusted.
E)
MAX output level controls
The maximum output level can be set with these potentiometers.
F)
Noise gate control
Sets the minimum input level, retaining a signal on the output. When the input signal is lower
than this level, there will be no output signal on the ALC-01. This function is very practical to
avoid hum and noise.
Please use signal cables shorter than 1 meter for the inputs and the outputs.
ALC-01
3
