RODEC
TABLE OF CONTENTS
- Specifications
- Use

- Safety instructions

- Installation
- Frontpanel
- Connections and control
- Installation and adjustment
- Noise gate
- Remote control option
- Sealing
- Pictures on cover
SPECIFICATIONS
- Noise gate trim:
- Controls:
- Remote VCA control:
- Measuring source:
- Frequency response:
- Signal to noise ratio:
- THD:
- Inputs:
- Outputs:
- Approbation:
- Power consumption:
- Dimensions:
- Weight:
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL ALC-01
SERIAL NUMBER ................................. (on the back of the set)
Please give model and serial number when info is requested.
Thank you very much for purchasing the RODEC audio level controller ALC-01.
USE
This audiolimiter will be placed in an existing audio installation between the mixing table (pre-amplifier)
and the power-amplifier. A particular maximum level can not be exceeded after placing and correct
regulation of the level controller. If the DJ tries to play a higher music level, the RODEC ALC-01
will regulate this back inaudible. Both on the frontpanel and on the remote-control (available as option)
a light will indicate when the maximum level is achieved.
SAFETY INSTRUCTIONS
1) Do not expose to rain or water. Do not spill liquid or insert (metal) objects inside . Rain, water
or liquid such as cosmetics as well as metal, may cause electric shocks, which can result in
fire or shock hazard. If anything gets inside, unplug the power cord.
Off / -80dB to 30dB
Max. input level (-18/+12dB), Gain (-35/+6dB)
(cable: 2wire + screen) off: 0dB range
Audio input signal (others optional)
10Hz - 25kHz
>87dB
<0.05%
+29.2dBm max./ 20kΩ balanced
balanced 100Ω
CE-approved
9VAC / 10VA (power adapter)
Front: 482mm x 44mm (19" x 1HE)
Chassis: 205mm x 44mm x 185mm
1.3 Kg Single 19" unit (unpacked)
2.2 Kg Dual 19" unit (unpacked)
ALC-01
- 2 -
- 2 -
- 2 -
- 3 -
- 3 -
- 3 -
- 4 -
- 4 -
- 4 -
- 4 -
- 18 -
2
