Owner's Manual
Unpacking the Game
Unpack your new dartboard carefully, ensuring all parts are included. The following components
are included in this set:
•
1 Electronic Dartboard
•
6 Darts (unassembled)
•
This owner's manual
THIS DARTBOARD MAY HAVE A PROTECTIVE FILM OVER THE SCORING DISPLAY –
REMOVE FOR BETTER CLARITY.
Batteries
This dartboard requires 4 x AA (1.5 volt) batteries to operate. Do not mix old and new batteries, and do not
mix alkaline, standard (carbon zinc), or rechargeable (nickel cadmium) batteries. Do not dispose of batteries
in fire - batteries may explode or leak. Batteries not included.
Setup/Mounting Instructions
Please insert the 4 x AA batteries into the dartboard before mounting to the wall. Choose a
location to hand the dartboard where there is around 10 feet of open space in front of the board.
The "toe-line" (oche) should be 8*0" from the face of the dartboard.
Locate a wall stud and place a mark 77.25" from the floor – this will be your guide for the top
mounting screw.
Insert mounting screw in the center of a stud using the mark you have made.
For extra support, 4x screws can be inserted through the catch ring area into the wall.
Center of bullseye should be 5'8" from the floor.
5'8'/1.73m
Bullseye
to Floor
8'/2.44m
1 | P a g e
TON MACHINE_INSTRUCTIONS_.indd 2-3 TON MACHINE_INSTRUCTIONS_.indd 2-3
Cricket Scoring Display
This dartboard utilizes a dedicated cricket scoreboard within the scoring display that keeps track
of each player's segment status when playing Cricket. When Cricket is selected, individual
characters will be utilized to register marks. There are 3 separate lights within each number (15
through 20 and bullseye). During play, one of the status lights will turn on (black will appear) as a
segment is hit. If a double or triple of an active number is hit, 2 or 3 lights will turn on respectively.
Important Notes
Caring for your Dartboard
DO NOT USE EXCESSIVE FORCE WHEN THROWING DARTS – this will cause frequent tip breakage and
cause excess wear on the board.
TURN DARTS CLOCKWISE WHEN PULLING FROM BOARD – This makes it easier to remove from the
board and extends the life of the tips.
REMOVE THE BATTERIES WHEN NOT IN USE FOR PROLONGED PERIODS OF TIME.
DO NOT SPILL LIQUIDS ON THE DARTBOARD – Do not use spray cleaners or use cleaners that contain
ammonia or other harsh chemicals that may cause damage.
Cleaning your Dartboard
Your dartboard will provide many hours of competition if cared for properly. Regular dusting of
the cabinet is recommended using a damp cloth. A mild detergent can be used if necessary.
Avoid the use of abrasive cleaners or cleaners that contain ammonia as this may cause damage.
Avoid spilling liquid on to the target area as this can result in permanent damage and is not
covered by warranty.
Darts
It is recommended that you do not use darts exceeding 24 grams on this dartboard. The darts
Toe-Line
included with this dartboard are 10 grams. Replacement tips are available at most retailers
/Oche
carrying dart products.
