ASSEMBLY AND SET-UP

① Aligne hole of the rear shock absorber and
hole of the rear fork.
② Put on M8*40mm cylindrical head screws with
socket head L cap, then covered with M8 nylon
lock nut at the other end.
③ Tighten the screws and nuts by a 6mm Allen
key and 13mm open-end wrench.
DO NOT USE NON-RCB PRODUCTS WITH
*
YOUR R9X ELECTRIC Scooter.
The R9X has been built to certain RCB design
specifications. The original equipment supplied
Rear shock absorber
at the time of sale was selected on the basis of
its compatibility with the frame, fork and all other
parts. Certain aftermarket products may or may
not be compatible.
Rear fork mount
09
