RF Rx SW868/SW915/SW917/SW922-USB
Telegrammaufbau / Funkempfänger
Telegram structure / Wireless receiver
English
sWave-Konfiguration
The radio behaviour of the sWave radio switches is set with the following two commands. LBT can be switched on and off here. LBT must be
switched on to deliver switch data reliably. In this case, the response time is slower by a few milliseconds, depending on the radio load.
A regular status telegram can be configured to monitor the remote switches at intervals of 10, 100, 1,000 and 10,000 seconds. The additional te-
legrams reduce the battery life of the remote switches.
CONFIG Byte
Bit 7
Meaning x
x: reserved
LBT bit
Value Meaning
0 LBT off
1 LBT on*
The LBT option is activated and the status telegram is deactivated in the factory settings (marked with an *).
NOTE
- The manual remote control (RFHB) does not send status telegrams and ignores this option.
- Only battery-powered transmitters support the sWave configuration.
- If a jumper is inserted in the transmitter to set the status signal, this jumper overwrites the setting of the receiver.
6 5
x x
4 3
x Status telegram interval
Status telegram interval bits
Meaning
Value
0 0 0 Status telegram off*
0 0 1 10-second interval
0 1 0 100-second interval
0 1 1 1,000-second interval
1 0 0 10,000-second interval
reserved
1 0 1
reserved
1 1 0
reserved
1 1 1
9 / 16
2 1 0
LBT
