Front Panel; Rear Panel - Fantec MM-FHDL Handbuch

32 GOTO
33
COPY
34 MUSIC
35 INFO

2.2 Front Panel

1. LCD screen
3. Power indicator & button

2.3 Rear Panel

1. Air Flow hole
3. USB HOST port x 2
5. RJ45 LAN socket
7. Y/Pb/Pr OUT jack
9. DC IN jack
Press to jump to a specific point on a title. Specify the point
using Title, Chapter and Time.
Press to enter the file copy menu.
Press to start playing music in the music playlist.
Press to hide or display the information bar during playback.
2. Working indicator
2. USB DEVICE port
4. S/PDIF COAXIAL & OPTICAL jack
6. HDMI jack
8. A/V OUT jack
10. SCART socket
ENGLISH
15 / 51
