Front Panel

1
1
DISC TRAY
2
AUX IN 1 CONNECTOR
3
DISPLAY
4
USB PORT
5
OPEN/CLOSE BUTTON (
6
FUNCTION BUTTON (
7
STOP BUTTON (
8
PLAY / PAUSE BUTTON (
9
VOLUME CONTROL BUTTON (
10
POWER BUTTON (
11
REMOTE CONTROL SENSOR

Description

2 3
AUX IN 1
Insert disc here.
Connect external components such as an MP3 player.
Displays the playing status, time, etc.
Connect here and play files from external USB storage devices such as MP3
players, USB flash memory, etc.
The USB memory that requires high power (more than 500mA at 5V) may
not be supported. (except iPod/iPhone which is compatible with 1A at 5V).
Opens and closes the disc tray.
)
The mode switches as follows :
)
DVD/CD ➞ D.IN ➞ AUX 1 ➞AUX 2 ➞ USB ➞ FM
Stops disc playback.
)
Plays a disc or pauses playback.
)
Volume adjustment.
, )
Turns the product on and off.
)
Detects signals from the remote control.
4 5 6 7 8
5V 500mA
9
10
11
11
