6. MAIN SCREEN PAGE

When the panel is switched on, the display unit shows the following sequence:
EXPRESS PRO
V. 1.0
At the end of the boot up sequence, the main menu is displayed, as described below.
This screen page displays a general view of the motor and system status:
- 230 V Power supply voltage reading;
- 7.0 A Total absorbed current;
- 10,0B Analog input value (here, 10.0 bar);
- M1 = 1 Motor 1 active;
- M1 = 0 Motor 1 deactivated;
- M2 = 1 Motor 2 active;
- M2 = 0 Motor 2 deactivated;
If no analogue sensors are used, no value for analogue input will be present in the main screen.
Only from this screen is it possible to access the settings menu by pressing and holding the SETUP
key for 3 seconds.
230V 7,0A 10,0B
M1 = 1
230V 7,0A 10,0B
M1 = 1 M2 = 1
E L E N T E K
elentek.com
230V 0,0A 10,0B
230V 0,0A 10,0B
M1 = 0 M2 = 0
MODEL 50Hz
SINGLE PHASE
M1 = 0
