BMS switch
To turn on/off the whole battery
Circuit breaker
To control manually the connection between the battery and external devices.
Wheel (Optional)
To help move and support your equipment
LCD screen
To indicate the state of the battery system
Condition
Normal
Abnormal
Upgrade
After initialized successfully, the LCD screen will be on
for long time and shows the SOC in percentage.
The screen stays on unless shutdown and dormancy
If the fault in the Table-4 occurs, the corresponding
fault code will be displayed on the LCD screen. For
details, refer to the Table-4.
When upgrading, the screen will be filled with the
"upd" as well as the upgrade process in percentage .
Table-3 LCD Screen
8
Status of Charge (SOC)
Error Code
Performance
