English - Hikmicro Pyrometer Schnellstartanleitung

1 Overview
The pyrometer is an intelligent temperature measuring instrument for harsh industrial
environments to measure high temperature and trigger alarms, which is designed to be flexible
and easy-to-install.
2 Appearance
2.1 Component
M50× 1.5 Thread
Objective
L-Bracket
2.2 Cable
The pyrometer has 2 standard cables, which can be used for power connection, temperature
and alarm signal transmission, etc.
Aviation Plug B
Aviation Plug A
Aviation Plug
Connects to the corresponding aviation socket of the pyrometer.
Network Plug
Connects to a switch or router for network supply.
Debug Port
For debugging by technicians only.
Shielded Cable
Prevents electromagnetic interference from the pyrometer's signal, connected to the earth
ground.
Waterproof
Vent Valve
Socket A
Protective
Cover
Network Plug
1

English

Screen
Socket B
Grounding
Screw
Terminal
Shielded
Cable
Debug Port
