15. TECHNICAL DATA
GB
Receiver
Dimensions in mm (W × D × H) ............................................................... 240 × 175 × 40
Weight in grammes:
Receiver
Remote control ........................................................................ 80 g (without batteries)
IF Input frequency range .................................................................. 950 MHz ~ 2150 MHz
IF-bandwidth ..................................................................... 55 MHz/8 MHz (below 5MS/s)
LNB power supply ............................................................................. 13/18 GS, 0,30 A max.
LNB controller ............................................................. 22 KHz ± 2 KHz, 0,6 V pp ± 0,2 V
DiSEqC controller ............................................................................ Version 1.0, Version 1.2
Symbol rate .............................................................................................................. 1 ~ 45 MS/s
Input speed ........................................................................................................... Max. 15 Mbit/s
Forward Error Correction (FEC) .............................. 1/2, 2/3, 3/4, 5/6, 7/8, auto
Aspect ratio
Video resolution ......................................................... 720 x 576 (Pal), 720 x 480 (NTSC),
Audio mode
Connection options
LNB IF input ....................................................................................................... Typ F, IEC 169-24
TV-SCART (output only) .................................................................... Video CVBS, Audio L, R
VCR-SCART (output and input) ....................................................... Video CVBS, Audio L, R
RCA (CINCH) ...................................................................................................................... Audio L,R
OPTICAL
HDMI port ................................................................ Connection for digital transmission of
USB
Power supply
Mains input voltage ....................................................................... 100-240 V ~ , 50/60 Hz
Power consumption
Operating temperature ..................................................................................... 0º C ~ +40º C
Storage temperature ............................................................................... – 40º C ~ + 65º C
Changes and errors excepted. Typographical errors subject to correction.
Installation Guide
..................................................................................................... approx. 1700 g
....................................................... 4:3 letterbox, 4:3 PanScan, 16:9
.............................................................. Left, right, stereo, AC3 digital sound
.................................................................................................... Digital audio output
....................................................................................................................... USB port
......................... Max. 25 W (when operated with single LNB)
Overload protection at peaks
1280 x 720, 1920 x 1080
audio and video signals
48
1 W (standby)
