6. CONNECTING THE RECEIVER
6.6 Connecting an audio digital receiver
If you want to use 5-channel audio transmission (Dolby Digital surround sound/AC3), you
must connect your audio digital receiver to the optical output of the receiver.
Warning!
Never connect the phono input on your stereo to the receiver; doing so can permanently
damage your stereo. Be sure to follow the instructions for connecting a Cinch cable in
the user guide for your stereo system.
Warning!
Be sure to follow the connection instructions in the user guide of your audio digital
receiver.
The optical cable does not come with the receiver.
Your TV set does not have to be turned on for radio reception.If you want to receive TV
sound over your stereo, you must turn the TV on.
Connecting the optical digital output
Plug the optical cable into the „OPTICAL" connection on the receiver.
Connect the optical cable to the audio digital receiver.
Connection diagram
17 DVB-S Receiver
