Strap. (Fig. 5.4)
This process will remove a thin strip of plastic from
your track.
MAINTENANCE
Fig. 6.1 - 6.4: Checking the 90° cutting angle (CCS)
Fig. 7.1 - 7.4: Checking the 90° cutting angle (CCSX)
Fig. 8.1 - 8.4: Checking the 45° cutting angle (CCSX)
DUST & DEBRIS COLLECTION
An adaptor nozzle (Fig.1.11) can be fitted to all CCS
machines. Fitting the nozzle allows the machine to be
connected to a dust/debris collection device.
Note: The exact design of the nozzle supplied will
vary depending upon type of model and the market
destination of the machine.
The supplied nozzle will accept a wide variety of debris/
dust collection devices currently available. The nozzle
should be fitted to the Cut Material Ejection Port.
Note: A workshop dust/debris extraction machine can
be attached to the adaptor nozzle if required. Follow the
manufacturers instructions if such a machine is fitted
and ensure that it is capable of handling the ejected cut
material.
LOWER BLADE GUARD
All CCS series machines have an automatic lower blade
guard which has a specially shaped leading front edge.
This feature ensures that the blade guard retracts
smoothly and effortlessly as the machines blade enters
the workpiece. As the blade exits the workpiece the
lower blade guard will automatically return to its normal
position covering the blade completely
If retracting the blade guard manually great care must be
taken to ensure that the operators hand or fingers do not
touch any part of the machines blade.
STORAGE
• Store the device and its accessories in a dry and
dustproof location. Store it out of the reach of
children.
• Store the bits separately to avoid mechanical damage
or confusion with other tools. Protect the bits from
excessive heat (e.g. by storing near heating pipes or
steam pipes) and from UV radiation.
• If you intend to store a battery for a period without
use then store battery at room temperature (0°C to
20°C) When storing for very long periods boost charge
the battery once per year to prevent over discharge.
The Ambient temperature range for tool and battery
use: 0°C to 40°C. The charging temperature: 5°C to
40°C.
