ADDITIONAL SAFETY INSTRUCTIONS FOR CIRCULAR
SAWS
• Wear a dust mask. Exposure to dust particles can be
harmful to your health and make it difficult to breath. Use
a dust extraction system and wear a suitable protective
mask.
• Do not use any abrasive wheels.
• Use only saw blades that comply with the
characteristics specified in this manual.
• Use only saw blade diameter(s) in accordance with the
markings.
• Use only saw blades with a speed marking that is
higher than or equal to the speed marked on the tool.
• Avoid heating the blade tips. Avoid overheating or
melting the materials. When cutting plastic, let the tool
do the work. Do not force the tool or cut too slowly which
could result in melting the plastic.
• Use only saw blades recommended by the
manufacturer, which conform to EN 847-1, if intended
for wood and analogous materials.
RESIDUAL RISKS
Even with application of safety standards and using the
tool as prescribed, certain residual risks can remain:
• Risk of personal injury due to prolonged use.
• Risk of injury caused by dust.
• Risk of injury caused by flying objects.
• Risk of burns due to accessories becoming hot.
• Risk of electric shock due to cutting through electric
cables. When cutting through floors, ceilings of walls
ensure there are no hidden cables or water pipes.
CLEANING AND MAINTENANCE
WARNING: Disconnect the battery pack from the
tool before any adjustments, cleaning, or maintenance is
carried out.
• Use compressed air to blow dirt out of the main
housing air vents and the blade guard. Wear approved
eye protection and a dust mask.
• Use a cloth dampened with water to clean the other
areas of the tool. Never use solvent based or harsh
chemicals of any type as this may weaken, damage or
destroy plastic components.
• Do not attempt to modify the tool or accessories in any
way.
• When servicing only use Evolution original parts and
carried out by a qualified person.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.
PRODUCT OVERVIEW KEY
1. Rafter hook*
2. Ergonomic front handle
3. Bevel locking lever
4. Parallel edge guide*
5. LED worklight
6. Lower blade guard
7. Saw blade
8. Dust port extractor
9. Hex key
10. Interlock safety button
11. On/Off trigger
12. Depth scale
13. Ergonomic rear handle
14. Battery
15. Depth adjustment locking lever
16. Upper blade guard
17. Bevel angle scale
18. Sole plate edge scale*
19. 90 degree set screw*
20. Track adjustment cams**
21. Track compatible base**
22. Secondary bevel angle lever/scale**
23. 45 degree bevel set screw**
24. 90 degree set screws**
25. Outer flange
26. Double sided inner flange
* R185CCS-Li only
** R185CCSX-Li only
USING THE PRODUCT
Getting Started
Fig. 1.1 - 1.14: Assembly of blade and accessories
Operation
Fig. 2.1 - 2.4: Adjusting the cutting height (CCS/CCSX)
Fig. 3.1 - 3.4: Adjusting the bevel angle (CCS)
Fig. 4.1 - 4.4: Adjusting the bevel angle (CCSX)
Fig. 5.1 - 5.4: Saw to track commissioning (CCSX)
Before the first use of the Evolution Cutting Track
the Splinter Guard Strip needs to match the saw and
blade.
To match the saw to the track:
• Fully assemble the Cutting Track as in the track
instructions.
• Clamp the track to the appropriate piece of spare
or scrap material.
• Evolution's cutting track compatible machines
have two (2) cams which project into the sole plate
channel. (Fig 5.1)
• With the blade removed adjust these cams so that
when the machine is placed correctly on a track it
can be moved forewards and backwards smoothly
without any lateral movement being detectable.
• Assemble the blade back on the saw without
moving the cams. (Fig. 5.2)
• Set the saw blade to maximum depth of cut.
• Ensure that no obstructions are present beneath
the path of the blade.
• Position the saw at the end of the track with the
front cam engaged on the track and the blade
before the Guard strip.
• Start the motor and allow it to reach full speed.
(Fig. 5.3)
• Smoothly and slowly push the circular saw along
the full length of the track until the blade has cut
through the entire length of the Splinter Guard
