⑧Trigger X position indicator arrow:
Indicates that this is the trigger point.
⑨Channel 2 waveform:
The waveform signal collected by channel 2.
⑩Trigger voltage indicator icon:
The trigger threshold.
⑪Channel 1 settings:
Long press the mode switch button to set the channel on/off, probe ratio, coupling type, and FFT.
⑫Channel 2 settings:
Long press the automatic measurement button to set the channel on/off, probe ratio, coupling
type, and FFT.
⑬Trigger settings:
Long press the run/pause button to set the trigger mode, trigger edge, and trigger channel.
⑭Parameter measurement:
Displayed according to the measurement item selected in the settings.
