Mounting with cable ties
Horizontal mounting
Guide the cable ties horizontally through the
universal bracket from the outside.
The serrated side of the cable ties must face
inwards.
Guide the cable ties vertically through the uni-
versal bracket from the outside.
The serrated side of the cable ties must face
inwards.
Attach the bracket to a vertical post, e.g. a picket
fence, pipe or gate post.
Attach the bracket to a horizontal cross strut,
e.g. slat, beam or pipe.
The bracket must always point upwards so that
the solar panel can later be pushed on from
Now slide the light body into the bracket from
Remove the mounting bracket from the
luminaire body
above.
above.
Vertical mounting
