F - HF LEVEL ADJUST – The High Frequency adjustment switch is used to increase or
decrease high frequency levels from the monitor system by +2dB or -2dB. This is useful
for lowering the HF level in a bright room or increasing for an acoustically dead room.
It is also useful for tailoring to a listening style preference; set these to room condition
and taste.
F - LF LEVEL ADJUST – The Low Frequency adjustment settings are boundary condition
filters. The -2dB setting rolls off the additional low-end that becomes present when the
monitors are set close to walls or other large hard surface boundaries. The +2dB setting
will add additional low-end if you need more low frequency content; set these to room
condition and taste.
G – POWER SWITCH – Main power switch for the system. Ensure the switch is in the
"ON" position to supply power to the system.
H - AC INLET SOCKET – A standard IEC320 Polarized C8 socket is used to provide power
to the studio monitor. Only use the provided AC power cord provided with your monitor.
KREATE 5 AND KREATE 8 SYSTEM CONNECTORS AND CONTROLS
Connectors and Controls are the same for the KREATE 5 and KREATE 8.
C
E
A - HF LEVEL ADJUST – The High Frequency adjustment switch is used to increase or
decrease high frequency levels from the monitor system by -2dB to +1dB. This is useful for
lowering the HF level in a bright room or increasing for an acoustically dead room. It is also
useful for tailoring to a listening style preference; set these to room condition and taste.
KREATE SERIES
H
KREATE 5 REAR PANEL
8
A
B
D
F
G
I
