B - LF LEVEL ADJUST – The Low Frequency adjustment settings are boundary condition
filters. The -1dB and -2dB settings roll off the additional low-end that becomes present
when the monitors are set close to walls or other large hard surface boundaries. The
+2dB setting will add additional low-end if you need more low frequency content; set
these to room condition and taste.
C - RCA INPUT – Unbalanced RCA input. Connection to audio interfaces, DJ mixers, or
consumer audio gear.
D - SYSTEM LEVEL – The level knob adjusts the system gain. Turn clockwise to raise the
volume and counterclockwise to reduce volume.
E - TRS INPUT – Balanced ¼" input. Connection to audio interfaces, mixing consoles, or
other professional audio equipment.
F - XLR INPUT – Balanced XLR input. Connection to audio interfaces, mixing consoles, or
other professional audio equipment.
G – POWER SWITCH – Main power switch for the system. Ensure the switch is in the
"ON" position to supply power to the system.
H - BLUETOOTH / STANDBY
PAIRING AND UNPAIRING: Bluetooth input for wireless audio streaming. Connect
to a Bluetooth-capable audio device, i.e., computer, iPhone, Android, media player,
etc. Push to pair: the blue LED will slow blink, and the pairing mode sound will
play when in pairing mode. The Blue LED will become a solid color and connection
sound will play when successfully paired. Extra-long pressing (10 seconds): the
button will disconnect the speaker from any connected device. Press the button
three times consecutively to bypass the automatic standby mode. Press the button
two times consecutively to enter automatic standby mode.
DEVICE LINK: Before attempting device link, make sure both speakers are not
connected to any other devices. Long press (3 seconds) on both speakers to
enter device link mode; blue LED will fast-blink. This mode can be initiated from
either speaker. Note that the speakers will not enter device link if they are already
connected to a device. The device link sound will play when successfully linked.
Once linked, the pairing mode sound will play, and the device will immediately
enter pairing mode. One of the speakers will have a slow-blinking LED and the
other will have a solid LED. The speaker with the blinking LED is designated as the
Left speaker and the speaker with the solid LED is designated as the Right speaker.
This designation will remain constant until the speakers are unlinked and relinked,
in which case the process will be repeated. Once paired to a device, both speakers
will have a solid blue LED. If the speakers are linked but disconnected from a device,
then the Left speaker LED will be off and the Right speaker LED will be solid. Extra-
long pressing (10 seconds) of the button on either speaker will unlink the speakers
and disconnect them from the device.
I - AC INLET SOCKET – A standard IEC320 C14 AC Inlet socket is used to provide power
to the studio monitor. Only use the provided AC power cord provided with your monitor.
