KREATE 3 SYSTEM CONNECTORS AND CONTROLS
The KREATE 3 system operates in a Main-Secondary configuration with the Left speaker
being the Main. All Controls are located on the Main Left speaker.
B
C
A - RCA INPUTS – Unbalanced RCA inputs. Connection to audio interfaces, DJ mixers,
or consumer audio gear.
A - AUX INPUT – Stereo 1/8" analog input. Connect to computer, media player, or cell
phone outputs.
B - TRS INPUTS – Balanced ¼" inputs. Connection to audio interfaces, mixing consoles,
or other professional audio equipment.
C - OUT TO RIGHT SPEAKER CONNECTOR – Speaker-level connection to the right
speaker via supplied 4-pin locking connector.
D - BLUETOOTH / STANDBY – Bluetooth input for wireless audio streaming. Connect to
Bluetooth-capable audio device, i.e., computer, iPhone, Android, media player, etc. Push
to pair; the blue LED will blink, and the pairing mode sound will play when in pairing
mode. Blue LED will become a solid color and connected sound will play when paired.
Long pressing (3 seconds) the button will disconnect from any connected device. Press
the button three times consecutively to bypass automatic standby mode. Press the
button two times consecutively to enter back into automatic standby mode.
E - SYSTEM LEVEL – The level knob adjusts the system gain. Turn clockwise to raise the
volume and counterclockwise to reduce volume.
KREATE SERIES
A
D
KREATE 3 LEFT REAR PANEL
7
E
F
G
H
ENGLISH
