RC 850 BL
12
1
11
LOCATION OF CONTROL
1. On/Off/Auto
2. Time Set
3. Alarm Set/Off
4. Sleep
5. Snooze button
6. Hour
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION : THE CLOCK RADIO MUST NOT BE USED IN ANY
ENVIRONMENT WHERE IT MAY BE SUBJECT TO THE DRIPPING OR
SPLASHING OR WATER OR OTHER LIQUIDS.
DO NOT CONNECT THE ANTENNA WIRE ON THE BACK OF THIS SET TO
ANY OUTDOOR ANTENNA
Mains plug is used as the disconnect device. It shall remain readily
operable and should not be obstructed during intended used. To
be completely disconnected the apparatus from supply mains, the
mains plug of the apparatus shall be disconnected from the mains
socket outlet completely.
BOTTOM OF SET : Battery compartment for 9V
(not included) for temporary time storage.
ELECTRONIC CLOCK OPERATION
1. Plug the AC line cord into 230V~ AC home outlet
2. The set is now working as an electronic clock and it will flash
the clock figures to show you it is not set correctly.
3. To set the correct time, depress the Time Set Button (2) and
Hour Button (6) simultaneously, release the buttons approxima-
tely before the correct time is reached. Now depress the Minute
Button (7) and the Time Set Button (2) simultaneously, to
set the readout to the correct time precisely.
RADIO OPERATION
1. Slide the ON/OFF/AUTO Switch (1) to "ON" position.
2. Slide Band Switch (9) to FM or AM position.
3. Turn the Volume Control (8) to desired volume.
4. Turn the Tuning Control (10) to select your favorite station.
5. Antenna
For AM reception, this radio incorporates a highly sensitive ferrite
core bar antenna.
For FM reception, this set is specially equipped with an external
wire as FM antenna. Be sure to untwist it to its fullest length for
peak performance.
2
2

AM/FM ALARM CLOCK

2
6
3
7
4
5
10
7. Minute
8. Volume Control / Buzzer
9. Band Switch
10. Tuning Control
11. AUTO indicator
12. HI-LO Dimmer
(6LR61) battery
WAKE TO RADIO
Having selected your station and set the volume at the desired
level, proceed as follows :
1. Slide the ON/OFF/AUTO Switch (1) to "AUTO" position.
2. Press the Alarm Set Button (3) and whilst this button is depres-
sed, press the Hour Button (6) and then the Minute Button (7)
until the time is reached at which you wish to wake. The wake
up time is now entered into the timer memory. To check the
8
wake up time, simply press the Alarm Set Button (3) and the
9
clock will show the present time. The preset wake up time will
continue to be registered in the time memory and the radio will
10
switch on by itself at the same time the next day. To switch
the radio off, simply press the Alarm Off Button (3).
When wake to radio is set, but want to listen radio before alarm
time set. Press SLEEP button (4) once will turn radio on and
press SNOOZE button (5) once will turn radio off.
WAKE TO BUZZER
Set the controls as for "Wake to Radio" but volume control (8) to
BUZZER position. The buzzer can then be switched off by pressing
the Alarm Off Button (3) or it can be converted to the radio by
selecting switch (1) to "ON" position.
SLEEP TO RADIO
The radio can be set to play and to switch off automatically for a
length of time from 1 minute to 1 hour 59 minutes by following
this procedure - With all the controls preset in the "Wake to Radio"
positions, depress the Sleep Button (4) and press the Minute Button
(7) to count down to the desired sleep time. To switch off the radio
before the end of the registered sleep time period, simply press
the Snooze Button (5).
SNOOZE CONTROL
The Snooze Button (5) allows the user an extra sleep time of about 9
minutes after radio alarm is switched on at the preset wake up time.
SPECIFICATION
Power Source ........................... : 230V ~ 50Hz
DC battery ................................ : 9V
Radio Frequency ....................... : AM 530-1600kHz:
Power Consumption
USERS INFORMATION pursuant to Legislative Decree No. 49 of March
14, 2014
"Implementation of Directive 2012/19 / EU on Waste Electrical and Electronic
Equipment (WEEE)"
This wheeled bin symbol on the product indicates that at the end of its life must be
collected separately from other waste. The user must, therefore, take the remote control
integrates the essential components that got to its life to the appropriate differentiated
collection centers for electronic and electro-technical waste, or return it to the dealer when
purchasing a new appliance of equivalent type, in terms of one to one, or one to zero for
equipment having longer side of less than 25 cm. Appropriate separate collection for the
decommissioned equipment for recycling, processing and environmentally compatible
disposal helps prevent negative impact on the environment and human health and promotes
recycling of the materials making up the product. Illegal dumping of the product by the
user entails the application of administrative sanctions stated in Legislative Decree n.
Legislative Decree No. 49 of March 14, 2014.
(6LR61, Not included)
: FM 88-108MHz
.............. : 3W
ENGLISH
