Type of cable
Category 5e cable or above should be used.

5.4 Communication

Close unused ports with the supplied rubber covers. Special notes for SFP modules:
1. Make sure that the SFP module is correctly aligned when plugging in the SFP module.
2. Slide the SFP module into the slot until it snaps audibly.
3. Note that the locking bracket of the SFP module is closed.
4. Plug the fiber optic cable with the LC connector into the SFP module until it snaps
sudibly.
5. When removing the SFP module, first pull the fiber optic cable.
6. Open the locking bracket of the SFP module.
7. Pull out the SPF module on the locking bracket.

6 LEDs and Error Signaling

The LEDs (green/red), which are visible on the front, indicate the following states.
Table 5: LEDs and Error Signaling
LED
Pos. Name Color
5 LNK/ Green
ACT
6 1000 Green
7 PoE Green
8 SFP Green
9 PWR Green
10 RPS Green
11 ALM Red
s08520000_00000016 V1.0.0 © 2020
En
Description
State
Lights up 10/100/1000 Mbit/s connection in operation
Flashes Data traffic via connection
Off Port disconnected or link failed
Lights up 1000 Mbit/s connection in operation
Off Port disconnected or link failed
Lights up Power feeding on PoE port
Off No power is feeding
Lights up SFP slot in operation
Flashes Data traffic via connection
Off Port disconnected or link failed
Lights up Use the primary power supply
Off Primary power off or failure
Lights up Use the redundant power supply
Off Redundant power off or failure
Lights up Failure of a port connection; miscellaneaous
alarm
Off No alarm to report
