Lichteigenschaften Der Wlb - Banner Wlb32 Bedienungsanleitung

Spezifikationen

Lichteigenschaften der WLB

Illuminance at a Distance
Center Beam (lux) Beam Width (m)
3682 lux 0.4 m
0.17 m
1979 lux 0.8 m
0.33 m
825 lux 1.2 m
0.50 m
1.6 m
439 lux
0.67 m
2.0 m
345 lux
0.83 m
2.4 m
223 lux
1.00 m
Vert.
Vertical Spread: 101.5°
Horizontal Spread: 128.8°
Illuminance at a Distance
Center Beam (lux) Beam Width (m)
4721 lux 0.4 m
0.17 m
2937 lux 0.8 m
0.33 m
1359 lux 1.2 m
0.50 m
785 lux 1.6 m
0.67 m
621 lux 2.0 m
0.83 m
451 lux 2.4 m
1.00 m
Vert.
Vertical Spread: 101.5°
Horizontal Spread: 128.2°
Illuminance at a Distance
Center Beam (lux) Beam Width (m)
5371 lux 0.4 m
0.17 m
3470 lux 0.8 m
0.33 m
1831 lux 1.3 m
0.50 m
1103 lux 1.7 m
0.67 m
899 lux 2.1 m
0.83 m
647 lux 2.5 m
1.00 m
Vert.
Vertical Spread: 102.7°
Horizontal Spread: 130.1°
29-Mai-25
285-mm-Ausführungen
Isolux Pattern
2 1
2
0.7 m
1.4 m
1
2.1 m
2.8 m
3.5 m
0 m
4.2 m
Horiz.
1
2
Mount height of 1 meter (1 m)
150 lux
125 lux
100 lux
570-mm-Ausführungen
Isolux Pattern
2 1
2
0.7 m
1.4 m
1
2.1 m
2.7 m
3.4 m
0 m
4.1 m
Horiz.
1
2
Mount height of 1 meter (1 m)
300 lux
250 lux
200 lux
850-mm-Ausführungen
Isolux Pattern
2 1
2
0.7 m
1.4 m
1
2.1 m
2.9 m
3.6 m
0 m
4.3 m
Horiz.
1
2
Mount height of 1 meter (1 m)
450 lux
375 lux
300 lux
© Banner Engineering Corp. Alle Rechte
vorbehalten. www.bannerengineering.com
WLB32 LED-Industrielichterleiste (DC) – Bedienungsanleitung
0 m 1 2
230
192
153
115
77
38
38
77
115
153
192
230
75 lux 10 lux
50 lux 5 lux
25 lux
1 2
0 m
460
383
307
230
153
77
77
153
230
307
383
460
150 lux 25 lux
100 lux 10 lux
50 lux
0 m 1 2
650
542
433
325
217
108
108
217
325
433
542
650
225 lux 25 lux
150 lux 10 lux
75 lux
Polar Candela Distribution
180°
170° 160°
150°
140°
0
40°
30°
20°
10°
Vertical Angle: 0°
0° Vertical 90° Horizontal
Polar Candela Distribution
180°
170° 160°
150°
140°
0
40°
30°
20°
10°
Vertical Angle: 0°
0° Vertical 90° Horizontal
Polar Candela Distribution
180°
170° 160°
150°
140°
0
40°
30°
20°
10°
Vertical Angle: 0°
0° Vertical 90° Horizontal
Illuminance at a Distance
page 9 of 16
130°
120°
110°
100°
90°
80°
70°
60°
50°
130°
120°
110°
100°
90°
80°
70°
60°
50°
130°
120°
110°
100°
90°
80°
70°
60°
50°
