d: Wire connection:
WARNLNG: To avoid possible electrical shock, be sure electricity is turned
off at the main fuse box before wiring
1. Plug one lead wire of fan (with 3P female connector) to the
corresponding female connector on the receiver(J).
2. Connect the black (Line voltage) wire from the outlet box to the black
wire from the receiver(J).
3. Connect the white (Neutral voltage) wire from the outlet box to the white
wire from the receiver(J).
4. Connect the green (Ground) wire from the outlet box to the green wires
from the hanger ball. mounting bracket(A)and receiver(J).
5. Secure the wire connection with the wire nut(AA) provided with the
electrical hard were.
6. After connecting the wires, spread them apart so that the green and
white wires are on one side of the outlet box.
9
