Genmitsu Cubiko Anweisung Seite 19

Step 1: Driver Installation
TIP:
1. If you are using Windows 11, this driver is already included in the system, and you
do not need to follow the driver instructions below. Please skip to Step 2.
2. If you are using a Windows 10 system but fail to successfully install the driver below,
you can also obtain the driver by directly updating to the Windows 11 system.
All files referenced should be on your SD card. If there are any problems with accessing these,
you can download a full copy of this from:
https://genmitsu.s3.us-east-1.amazonaws.com/101-60-CUBK/Candle/
1. Install the Windows Serial port driver, labeled CH341SER
Please note that the file linked is stored in a compressed .zip file. To use it, you must
extract the full contents of the .zip to a designated folder and then try running the file from
there. Running files from the .zip directly will not work.
2. Once you have found CH340SER.exe, right-click it and select "Run as administrator" and
authorize the programs to make changes to your computer. From there, just follow the
installation process, and you are done with this step.
Step 2: Software "Installation"
This is a free and open-source program that talks to your CNC via a serial USB connection
and provides a variety of functions. Candle can also be downloaded on its own for Windows
from: https://github.com/Denvi/Candle/releases/download/v1.1/Candle_1.1.7.zip
1. Open the folder (software → Grbl control (Candle_1.1.7 ) → Candle.exe.) and find the
primary file, Candle.exe, and create a shortcut to your desktop as shown below:
(software→Driver→CH340SER.exe).
15
